Odyssey Clutch v2 Freecoaster Hub
MSRP: $ 189.99



The Clutch v2 Hub is a traditional clutch-based coaster hub design that eliminates all of the problematic elements on ordinary hubs and only keeps the parts that work. A new, super-strong FULL 14mm axle, bearing configuration, and drag mechanism design stops the need for constant repairs. Equipped with external slack adjustment, which can be done with a 2.5mm hex key through a hub shell access hole (can be adjusted without removing the wheel), and an improved plastic hub guard spec.
Same Clutch coaster hub you’ve come to love, but with a few upgrades.

Available in Black and Polished.

FEATURES

  • 14mm chromoly axle bolts on both the drive and non-drive side for greater reliability
  • Improved clutch engagement
  • Crankflip ready
  • More slack than the v1 hub
  • Improved manufacturing precision throughout
  • All-new durable proprietary plastic spec for the removable hub guard
  • Protected by US Patent 9,469,157
  • Super-durable bearing arrangement throughout
  • Maximum strength axle design
  • Unique external slack adjustment feature
  • Super-durable drag mechanism design
  • Available in RHD and LHD
  • $189.95 USD Retail (Hub and Guard)
  1. COMPLETE WHEEL OPTIONS
  2. Laced to a HAZARD LITE RIM
  1. SPECS
  2. 36-hole, 2014-T6 aluminum shell
  3. 9t Driver
  4. LHD or RHD
  5. 22.5 oz / 640g
  1. SLACK ADJUSTMENT
  2. 2.5mm hex key through a hub shell access hole. No wheel removal required.
  1. GUARD OPTIONS
  2. Plastic hub guard included (but optional to use)
  1. MEASUREMENTS
  2. Drive Side Effective Flange Diameter: 56mm
  3. Non-Drive Side Effective Flange Diameter: 49mm
  4. Drive Side Flange to Center Distance: 27.5mm
  5. Non-Drive Side Flange to Center Distance: 27.5mm
