BSD Jonesin' Frame Graphite
BSD Jonesin' Frame Graphite MSRP: $ 379.99
The JONESIN’ frame is Sam Jones signature frame. As you may know Sam is a master of front end tricks and he designed his new frame with a steep 76° headangle, short 12.7-13.2" rear end and a 8.9” standover as well as using our new superscoop chainstay tubing for added tire clearance. Nozztastic!!
- Sam Jones signature
- Superscoop Chainstay: Our new Superscoop chainstay provides more tire clearance for when your wheel is slammed. The tubing is press formed post bending to create extra room where it's needed most without the need for an invest cast yoke.
- Invest Cast Dropouts: The dropout is cast as one piece, much stronger than a plate welded to a tube. 7mm thick to provide good support for your axle, and the small shape has been designed for grinding meaning there's no overhang to catch on ledges or rails, also the dropout is heat treated before welding making it extra tough. And finally there are integrated chain tensioner bolts inside.
- Integrated Seat Clamps: The seatclamp is built into the frame so there's no need for a separate clamp. This keeps the frame clean and simple while also allowing the seat to be slammed lower. Also the slot cut beneath the seatclamp gives more clamping power less torque on the bolt.
- Sanko Japanese seamless 4130 chromoly tubing
Top Tube Lengths: 20.4", 20.6", 20.8" & 21"
Head Tube Angle: 76°
Seat Tube Angle: 71°
Bottom Bracket Height: 11.7”
Chainstay Length: 12.7 - 13.2"
Weight: 5 lbs.
*BSD brake mount kit available separately.
