Fairdale Express Matte Royal Blue in S/M & M/L

Fairdale Express Matte Royal Blue in S/M & M/L MSRP: $ 499.00

Options MSRP
Small/Medium $499.00 SKU: FDX-282-MBU
Shipping: 53x8x26", 37.0lbs
Medium/Large $499.00 SKU: FDX-283-MBU
Shipping: 53x8x27", 37.0lbs

The Express is a fast machine for urban riding, commuting and fun. A key feature on this bike is its riding position. Low-rise mountain bike style handlebars put you into a commanding and stable riding position for zipping through busy areas.

Features like wide Continental tires, a simple single-speed drivetrain and a tough steel frame mean this bike will be a joy to ride for years. Feel free to configure your Express with a wide array of aftermarket racks and fenders, thanks to the standard rack mounting points on the frame and fork.

Don’t overthink or over-complicate the bicycle, just hop on an Express and ride.

Available in Matte Royal Blue in Small/Medium and Medium/Large sizes.

Sizing

Small/Medium: 5'2" - 5'8" height
Medium/Large: 5'6 - 6'0" height

Sizing is approximate. Please consult with your local bike shop to assist with fit.

Specifications

Frame: 1020 Steel, with Rack and Fender mounts
Fork: 1020 Steel, 1 1/8”
Handlebar: Fairdale Archer v3, Aluminum
Stem: 70mm, Forged Aluminum
Headset: FSA, Sealed Integrated, 45º/45º
Brake Lever: Aluminum, Short Pull
Brake: Aluminum, Dual Pivot, w/ Quick Release
Grips: Fairdale Swan
Saddle: Fairdale Logo Saddle
Seat Post: Micro adjust, 27.2mm
Seat Clamp: Fairdale, 30mm
Cranks: FSA Tempo 1x (S/M=170mm, M/L=175mm)
Chainwheel: 42t
BB Parts: FSA
Pedals: Odyssey Twisted PC
Rims: 700c, 36-Hole, Schrader Valve, Aluminum
Front Hub: 36H 3/8” Axle, Aluminum Shell, Looseball
Rear Hub: 36H 3/8” Axle, Aluminum Shell, Looseball
Tires: Continental Tour Ride, 700c x 42mm
Chain: KMC S1
Driver: 16t Freewheel

Geometry

Size S/M (52cm) M/L (56cm)
Top Tube (Effective) 537mm
565mm
Top Tube (Actual) 517mm
546mm
Seat Tube (BB Center to TT Top) 475mm
525mm
Seat Tube
(BB Center to TT Center)
439mm
489mm
Seat Tube Angle 73° 73°
Head Tube Length 130mm
155mm
Head Tube Angle 71° 72.5°
Chain Stay Length 430mm
430mm
Wheelbase 1018mm
1031mm
Standover 770mm
809mm
Stack 554mm
584mm
Reach 368mm
387mm
Fork Length 404mm
404mm
Fork Offset 50mm
50mm
BB Drop 68mm
68mm
Dropout Spacing 130mm
130mm
BB Type English 68mm
English 68mm
Seat Post 27.2mm 27.2mm
Seat Clamp 30mm 30mm
Approx. Max Tire Width 42mm
42mm
Wheel Size 700c 700c

*Specs subject to change without notice.
