BSD ALVX AF Frame Ice Blue
BSD ALVX AF Frame Ice Blue MSRP: $ 379.99
The ALVX AF is the latest incarnation of the ALVX frame, this new version features a super tech invest cast chainstay yoke which gives even more tire clearance as well as stiffening up the rear triangle. Your wheel can be slammed at an extremely short 12.5" CS length with no worries of your tire rubbing!!
- Alex Donnachie signature
- Super short rear end slammable to 12.5”
- External gussets
- Extra wide rear end for up to 2.4” tyres - No brake mounts
- 7mm thick invest cast dropouts - Built in chain tensioners
- Sanko Japanese seamless 4130 chromoly tubing
Top Tube Lengths: 20.3”, 20.6”, 20.8” & 21"
Head Tube Angle: 75.5°
Head Tube Length: 117mm
Seat Tube Angle: 71°
Bottom Bracket Height: 11.7”
Chainstay Length: 12.5 - 13”
Weight: 5 lbs.
*BSD brake mount kit available separately.
